LPG Gas Storage Tank, LPG Gas Tank Equipment, LPG Gas Tank Container

Large Image : LPG Gas Storage Tank, LPG Gas Tank Equipment, LPG Gas Tank Container

Product Details:

Contact Now

LPG Gas Storage Tank, LPG Gas Tank Equipment, LPG Gas Tank Container

Description

Model NO.:	WET-02	Storage Medium:	Moncombustible/Nontoxic
Pressure Level:	Medium Pressure (1.6MPa≤p<10.0MPa)	Condition:	New
Transport Package:	Tank Container	Specification:	Customize
Trademark:	WellCare	Origin:	China
HS Code:	7309000000	Production Capacity:	100 Set/Sets Per Month

Cryogenic Liquid Oxygen ISO Tank

The 20-foot ISO framework type tank container is applicable to Intermodal transportation. Marine, highway, and railroad
transportation.With its overall dimensions conforming to the ISO standards,the tank container has a rating for as high as 9 high stacking loaded. We work directly with each customer to ensure their specific needs are met. Our ISO tank containers can be heated or non-heated, insulated or non-insulated with multiple storage capacities.
We meet all safety standards and regulations so customers can transport a variety of liquids, including water, fuel, foos-grade products, hazardous chemicals, Bitumen, compressed gases and more. All ISO tanks are designed to meet your specific needs.

Our Tank Contanier Advantages:

Excellent corrosion resistance;
Low permeability of drugs and gases;
Excellent cleaning performance;
The price is moderate;
Excellent and stable welding performance;
It has the characteristics of high purity and no extractables;
Excellent adhesion and stability
LPG Gas Storage Tank, LPG Gas Tank Equipment, LPG Gas Tank Container

Name	Parameter
Model	20Ft
Working Pressure(Inner Tank)	2.2MPa
Design Temp(Inner Tank)	-196°C
Inner Material	SA240M
Outer Material	Q345R
Insulation Type	High Vacuum multilayer
Inner tank wall thickness	8mm
Outer tank wall thickness	5mm
Loading medium	LO2,LN2,LAr
Design standard	a.GB150 <Pressure Vessels> b.GB/T 18442< Cryogenic >Insulation Pressure Vessels> c.TSGR0004 <Pressure Vessels' Safety Technical Supervision Rules> d ASME CE CU-TR if Special requirements
We can customize the cryogenic tank of special capacity and pressure with different design standard or certificate(GB ASME CE CU-TR INMETRO etc)
