Product Details:
|
| Model NO.: | Tank Container In Truck Trailer | Storage Medium: | Moncombustible/Nontoxic |
|---|---|---|---|
| Pressure Level: | Medium Pressure (1.6MPa≤p<10.0MPa) | Condition: | New |
| Size: | Customized | Transport Package: | Tank Container |
| Specification: | Customize | Trademark: | WellCare |
| Origin: | China | HS Code: | 7309000000 |
| Production Capacity: | 100 Set/Sets Per Month |
Our Tank Contanier Advantages:
| Name | Parameter |
| Model | 20Ft |
| Working Pressure(Inner Tank) | 2.2MPa |
| Design Temp(Inner Tank) | -196°C |
| Inner Material | SA240M |
| Outer Material | Q345R |
| Insulation Type | High Vacuum multilayer |
| Inner tank wall thickness | 8mm |
| Outer tank wall thickness | 5mm |
| Loading medium | LO2,LN2,LAr |
| Design standard | a.GB150 <Pressure Vessels> b.GB/T 18442< Cryogenic >Insulation Pressure Vessels>
c.TSGR0004 <Pressure Vessels' Safety Technical Supervision Rules> d ASME CE CU-TR if Special requirements |
| We can customize the cryogenic tank of special capacity and pressure with different design standard or certificate(GB ASME CE CU-TR INMETRO etc) | |
