Product Details:
|
| Model NO.: | ISO Tank Container | Storage Medium: | Moncombustible/Nontoxic |
|---|---|---|---|
| Pressure Level: | Medium Pressure (1.6MPa≤p<10.0MPa) | Condition: | New |
| Transport Package: | Tank Container | Specification: | Customize |
| Trademark: | WellCare | Origin: | China |
| HS Code: | 7309000000 | Production Capacity: | 100 Set/Sets Per Month |
Our Tank Contanier Advantages:
| T3 Type Portable 20ft ISO Bitumen Container: | |||
| Frame Dimensions (L x W x H) | External | 6058 x 2438 x 2591 | MM |
| 20 x 8 x 8.5 | FT | ||
| Max. Capacity (Nominal) | 20,000 | CBM | |
| Max. Gross Weight | 30,480 | KGS | |
| Tare Weight (Nominal) | 6,700 | KGS | |
| Max Payload | 23780 | KGS | |
| Pressure | Working pressure | 1.76 | Bar |
| Test pressure | 2.65 | Bar | |
| Design Temperature | Frame | -20ºC to +170 ºC | |
| Tank | |||
| Material | Frame | GB/T 1591-Q345D | |
| Tank | 16MnDR | ||
| Thickness | Shell | 6.0mm | |
| Ends | 6.0mm after forming | ||
| Corner Casting | ISO 1161 - 8 off, 8pcs | ||
| Approval | IMDG T3, CFR 49, ADR/RID, CSC, TC, TIR, ISO, US/UK DOT | ||
