Product Details:
|
| Model NO.: | Cng High Pressure Cylinder | Storage Medium: | Moncombustible/Nontoxic |
|---|---|---|---|
| Pressure Level: | High Pressure (10.0MPa≤p<100.0MPa) | Condition: | New |
| Size: | Customized | Transport Package: | Nylon, Box, Transparent PP Bag |
| Specification: | 219/229/232/279/325/356/406mm | Trademark: | Wellcare |
| Origin: | China | HS Code: | 76130010 |
| Production Capacity: | 100, 000 Pieces For One Year |
CNG-1
| Type | Liner Outside Dia.(mm) | Design wall Thickness(mm) | Material | Nomial Capacity(L) | Nominal Length(mm) | Nominal Weight(kg) |
| ISO11439-200-V-356 | 356 | 7.7 | 34CrMo4 | 60 | 831 | 68.0 |
| 65 | 878 | 72.0 | ||||
| 70 | 941 | 76.0 | ||||
| 75 | 996 | 80.0 | ||||
| 80 | 1051 | 84.0 | ||||
| 90 | 1161 | 92.0 | ||||
| 100 | 1271 | 100.0 | ||||
| 150 | 1821 |
