Product Details:
|
| Model NO.: | LPG Cylinder | Storage Medium: | Moncombustible/Nontoxic |
|---|---|---|---|
| Pressure Level: | Medium Pressure (1.6MPa≤p<10.0MPa) | Condition: | New |
| Customized: | Accepted | Transport Package: | Black Net |
| Specification: | 3 - 20 Kg | Trademark: | Wellcare |
| Origin: | China | HS Code: | 7311009000 |
| Production Capacity: | 100, 000 Pieces For One Year |
| Model Number | Diameter (mm) | Height (mm) | Weight | Working Pressure | Execution standards | Thickness(mm) | Bottle body material |
| 5kg LPG Cylinder | 250mm | 420 mm | 6.5kg | 210 bar | GB/T5842 | 2.0mm | HP295 |
| 10kg LPG Cylinder | 250mm | 540 mm | 13kg | 210 bar | GB/T5842 | 2.5mm | HP295 |
| 15kg LPG Cylinder | 314mm | 680 mm | 16kg | 210 bar | GB/T5842 | 2.5mm | HP295 |
| 50kg Single Valve LPG Cylinder | 400mm | 1180 mm | 51kg | 210 bar | GB/T5842 | 3.2mm | HP295 |
| 50kg Double valve/adapter fitting LPG Cylinder | 400mm | 1180 mm | 51kg | 210 bar | GB/T5842 | 3.2mm | HP295 |
