Product Details:
|
| Model NO.: | WEOC05 | Storage Medium: | Oxygen |
|---|---|---|---|
| Pressure Level: | High Pressure (10.0MPa≤p<100.0MPa) | Condition: | New |
| Transport Package: | Nylon, Box | Specification: | 5 L 10 L 20 L 40 L |
| Trademark: | WellCare | Origin: | China |
| HS Code: | 761300900 | Production Capacity: | 100, 000 Pieces For One Year |
Hangzhou Wellcare Oxygen cylinder features:
1.It is equipped with valve, regulator, humidifier and nasal cannula
| Model No. | Outer Dia. (mm) | Volume (L) | Working pressure (bar/psi) | Test pressure (bar/psi) | Length without valve (mm) | Weight without valve (kg) |
| 7oz/M2 | 51 | 0.3 | 124bar/1800psi | 207bar/3000psi | 238 | 0.37 |
| 9oz | 54 | 0.38 | 124bar/1800psi | 207bar/3000psi | 245 | 0.38 |
| 12oz | 64 | 0.51 | 124bar/1800psi | 207bar/3000psi | 245 | 0.49 |
| 16oz/M4 | 81 | 0.68 | 124bar/1800psi | 207bar/3000psi | 205 | 0.72 |
| 20oz | 81 | 0.85 | 124bar/1800psi | 207bar/3000psi | 245 | 0.80 |
| M4 | 91 | 0.787 | 207bar/3000psi | 350bar/5000psi | 230 | 1.25 |
| M6 | 81 | 1 | 153bar/2216psi | 255bar/3695psi | 295 | 1.1 |
| ML6 | 111 | 1.08 | 139bar/2015psi | 232bar/3360psi | 195 | 1.34 |
| M9/MC/2.5lbs(co2) | 111 | 1.68 | 139bar/2015psi | 232bar/3360psi | 280 | 1.75 |
| MD | 111 | 2.75 | 139bar/2015psi | 232bar/3360psi | 423 | 2.45 |
| M22 | 133 | 3.9 | 139bar/2015psi | 232bar/3360psi | 420 | 3.3 |
| 5lbs(co2) | 133 | 3.35 | 124bar/1800psi | 207bar/3000psi | 369 | 3 |
| ME | 111 | 4.55 | 139bar/2015psi | 232bar/3360psi | 650 | 3.6 |
| 10lbs(co2) | 175 | 6.7 | 124bar/1800psi | 207bar/3000psi | 430 | 6 |
| M60/15lbs(co2) | 184 | 10 | 153bar/2216psi | 255bar/3695psi | 581 | 9.6 |
| 20lbs(co2) | 203 | 13.4 | 124bar/1800psi | 207bar/3000psi | 600 | 10.8 |
| M90 | 184 | 15.2 | 153bar/2216psi | 255bar/3695psi | 830 | 13.7 |
| M122/MM | 203 | 21 | 153bar/2216psi | 255bar/3695psi | 907 | 20 |
Our advantages:
| Type | gas cylinder | Outside diameter | 89-267mm |
| Water capacity | 2-80L | Height | 430-1815mm |
| Working pressure | 150-300Bar | With Cap Height | 490-1900mm |
| Test pressure | 250-450Bar | Weight | 3.4-80kg |
| Design wall thickness | 1.9-6.0mm | Material | aluminum |
| Storage gas | 0.3-15M3 | ||
| Color | Green, Black, White, Blue, Yellow, as Requested/as per your requested | ||
| Filling medium | Air, oxygen, argon, hydrogen, helium, nitrogen, carbon dioxide, spacial gas and mix gas | ||
| Packing | 1.bulk loading; 2.packed in plastic woven net; 3.packed in wooden pallets; 4.as required. | ||
| About | As a China gas cylinder manufacturer, we offer Oxygen Gas Cylinder, Nitrogen Gas Cylinder, Argon Gas Cylinder, CO2 Gas Cylinder, Hydrogen Gas Cylinder, Helium Gas Cylinder, Acetylene gas cylinder, CO2 Cartridge and Aluminum Cylinder … CE/TUV | ||
