Product Details:
|
| Model NO.: | Ammonia Decomposition Maintenance | Customize: | Available |
|---|---|---|---|
| Transport Package: | Container Loading | Specification: | Rolling Type / Skid-Mounted |
| Trademark: | WellCare | Origin: | China |
| HS Code: | 8419601100 | Production Capacity: | 100 Sets Per Month |
1. Brief Introduction
| Type | 5 | 10 | 20 | 30 | 40 |
| Rated gas output(Nm3/h) | 5 | 10 | 20 | 30 | 40 |
| Rated ammonia consumption (kg/h) | 2.0 | 4.0 | 8 | 12 | 16 |
| Rated heating power of generator (kw) | 6 | 12 | 29 | 39 | 50 |
| Rated heating power of purifier (kw) | 2 | 4 | 6 | 8 | 10 |
| Rated furnace temperature of generator(°C) | ≤800 | ||||
| Recycling heating temperature of purifier(°C) | 250 | ||||
| Rated power voltage (V) | 380 | ||||
| Dew point of gas purified(°C) | ≤-60 | ||||
| Remnant ammonia content of gas purified (PPM) | ≤10 | ||||
| Catalyzer | Nickel catalyst | ||||
Product Feature
Our PSA Nitrogen Generator has many advantages, such as high purity, simple process, full automation, low
operating cost and so on. And it is widely used in many industry, such as Food packing, Food storing, Electric & Electronic industry, Petrogas & Oil field, Chemicals & Petro-chemicals, Coal-mine, Metallurgy, Pharmacy, SMT, Fire-resistance, lab, Air driving, and so on.
All systems are designed for un-attended operation and automatic Nitrogen demand adjustment.
The lifetime is long and it's easy replace and maintain for the compressor air purification components.
The output flow of exit is large and the pressure of exit can adjust in the a setting range.
The Nitrogen purity can reach to > 99.99% without other nitrogen purification equipment. If add the nitrogen purification equipment, the purity can reach to>99.999%.
Low investment and energy consumption.
Simple operation and maintenance.
