440L/470L/520L Liquefied Gas Storage Gilbarco Fuel Dispenser for Your Convenience

Large Image : 440L/470L/520L Liquefied Gas Storage Gilbarco Fuel Dispenser for Your Convenience

Product Details:

Contact Now

440L/470L/520L Liquefied Gas Storage Gilbarco Fuel Dispenser for Your Convenience

Description

Model NO.:	WGFD-00	Pressure Level:	High Pressure (10.0MPa≤p<100.0MPa)
Volume:	440L/470L/520L	Storage Medium:	Liquefied Gas
Transport Package:	Bulk Load	Specification:	CNG Gas Resources
Trademark:	WellCare	Origin:	China
HS Code:	8413709990	Production Capacity:	10000 Sets Per Year

L_NG Dispenser Series of CNG Gas Filling Stations
Basic type	Mass flow CNG dispenser	Single-line single-hose, single-line dual-hose, single-line four-hose
		Dual-line single-hose, dual-line dual-hose, dual-line four-hose
		Three-line single-hose, three-line dual-hose, three-line four-hose
Technical Parameters	Applicable medium	LNG
	Accuracy measuring	±1.0%
	Range of flow	(2-30)kg/min(3-40)Nm³/min
	Rated working pressure	20MPa
	Max. working pressure	25MPa
	Compressive strength	37.5MPa
	Ambient temperature	-40ºC-+50ºC
	Explosive-proof grade	Exd AT4Gb
	Power supply	220V±15% 50Hz±1Hz
	Unit of measurement	Kg/Nm³
	Minimum scale reading	0.01
	Single counter range	0~9999.99
	Totalize range	0~99999999.99
	Rated power	Single-hose:100W,dual-hose:200W, Four-hose:400W

L-CNG Station Complete Equipment CNG stations Parameters of Single Pump Single Tank Ability on CNG Fueling Station:

1: Single pump single tank is the basic configuration for LNG/LCNG combined station with covering small area, low investment and good economy on CNG stations;

2: Natural gas storage capacity of about 30,000 M3 of CNG stations;

3: At the basis of single pump, double pump single tank has added a submersible pump and 1-2 sets liquid charging device CNG stations;

4: This configuration greatly enhance the station filling capacity. If a single pump or single liquid on CNG Fueling Station;

charging device needs to be maintained and overhauled, the another one can work properly without affecting the operation of the CNG Fueling Station;

5: Capacity of CNG Fueling Station for filling the vehicle per day on Natural Gas Fueling Station;

LNG: 50-80 set(450L single tank car) on CNG Fueling Station;

CNG stations: 50-200 set (Taxi)

Applicable media	CNG
Metrological accuracy	±0.5%
Rated flow rate	30Nm³/min(Standard dispenser) 40 Nm³/min(High-flow dispenser) 80 Nm³/min(Discharge column) 90 Nm³/min(Aerated column)
Unit of measure	Nm³ or KG
Applicable pressure range	The system design pressure is 27.5 Mpa The working pressure is 25 Mpa The rated working pressure is 20Mpa
Ambient temperature	-25ºC ~+55ºC(-40ºC ~+55ºC)
Ambient humidity	≤ 95%
Power adaptability	220VAC+10%-15%, 50Hz±1Hz
power	Below 200W
sign	ExdeibmbIIA T3 Gb

L-CNG Station Complete Equipment CNG stations High Pressure Gasifier Skid on Natural Gas Fueling Station:

The main equipment on Natural Gas Fueling Station of the high-plunger pump skid on CNG stations is the pressure plunger pump,and the skid of CNG stations is equipped with automatic control remote control valves, pressure sensors and temperature sensor on CNG stations.

The pipelines and valves before the pump on the skid all use vacuum to keep cold on order to ensure the safe operation of the plunger pump on CNG stations.
The overall structure of the skid body is compact and reasonable, covering small area, easy to lift, install and maintain at Natural Gas Fueling Station.

L-CNG Station Complete Equipment CNG stations High Pressure Skid-mounted Gasifier at CNG Fueling Station:

High pressure skid-mounted gasifier is equipped with high pressure gasifier on CNG Fueling Station, two sets electric heating water bath heater, EAG heater, order control panel,etc.
The equipment has reduced the installation work greatly with safe and reliable performance, beautiful appearance.
High pressure Air bathed Vaporizer can change the low pressure L-CNG which comes from the high pressure piston pump into the normal temperature high pressure natural gas (that is CNG). Each station has 2 gasifiers (one running and one standby)with alternating use. It adopts to the ordinary fin drawn stainless steel tube process to complete 30MPa pressure capacity.
Type: Vertical Natural Gas Fueling Station
Heat transfer type : Air bathed type Natural Gas Fueling Station
Designed gas capacity 1000 Nm3 /h -2000 Nm3 /h
Working Pressure of Natural Gas Fueling Station : 25MPa.G
Design Pressure : 30MPa.G
Inlet Pressure of Natural Gas Fueling Station: -160~-137ºC

Outlet Temperature :Lower 5~10ºC than the environment temperature on Natural Gas Fueling Station

Design equipments of lng gas filling station:
Gas Station Gilbarco Fuel Dispenser
