Product Details:
|
| Model NO.: | WGA-01 | Storage Medium: | Moncombustible/Nontoxic |
|---|---|---|---|
| Pressure Level: | High Pressure (10.0MPa≤p<100.0MPa) | Condition: | New |
| Certificate: | ASME | Transport Package: | Packed With Wooden Pallet |
| Specification: | 0.16L/0.32L/0.5L/0.75L/1L/1.4L/2L/2.5L/2.8L | Trademark: | WellCare |
| Origin: | China | HS Code: | 8479899990 |
| Production Capacity: | 200000 Pieces Per Year |
| Condition | New |
| Warranty | 3 months |
| Showroom Location | None |
| Type | Diaphragm accumulator |
| Brand Name | WellCare |
| Place of Origin | Zhejiang, China |
| Pressure | 20 Mpa / 30 Mpa |
| Standard nitrogen valve | 5/8" UNF |
| Nitrogen load valve thread | 5/8" UNF |
| Weight | 8.5 |
| Part nº | R1 | Max. flow (l/min) | Max. Press. (bar) | Nitrogen vol. (l) | Image nº | A | B | C | D |
| HST 2.3 | M18*1.5 | 55 | 307 | 2.3 | 2 | 340 | 165 | 22 | 138 |
| 1. What is the manufacturing standard or directive? We can produce the bladder accumulators according to PED2014/68/EU, AD2000, EN14359:2006, ASME, Selo or supply doube certificates according to customer's requirements. | |
| 2. What is the inspection mould of CE bladder accumulator shells? We supply mould G inspection according to PED2014/68/EU. 3.What is your main export market? We mainly export our bladder accumulator shells to Europe, America, Asia, middle east countries. 4. What is the delivery time? Generally we supply the goods within 45days after receipt of the deposit. 5.What is your terms of payment? We accept T/T, 30% deposit, the balance against copy B/L or irrevocable LC at sight. | |
| 6.What is your advantage? We have full experience of producing bladder accumulator shells since year 1979. Quality is our culture! |
